DVB-S2(DVB-C/DVB-T) Receiver Decoder with HDMI/SDI/ASI/IP outputs


Professional HD DVB-S2 Integrated Receiver Decoder with SDI HDMI IP output, CAM/CI slot, supports AC3, 1Ch Tuner, ASI, IP de-scrambling

  • Supports DVB-S2 Input (QAM, DVB-C, DVB-T/T2, ATSC-T, DVB-S/S2, DMB-T and ISDB-T RF Input Optional)
  • SupportsLCD display for decoding video
  • SupportsMPEG-2 & MPEG-4 video decoding
  • SupportsAC3 pass through
  • Re-multiplexer embedded
  • SupportsTuner, IP, ASI Input at the same time
  • SupportsIP, ASI, Decoding output at the same time
  • Supports8xSPTS/32xSPTS and1 IP MPTS output
  • SupportsCAM/CI card insert
  • SupportsBISS descrambling: Mode 1 and Mode E
  • Supports CC (Closed Caption)
  • Supports Front Panel and NMS/SNMP network management and Web management

QuestTel B-IRD-HD-PRO-Q is flexible for any application and can receive signals from Tuner DVB-S2 or Optional Tuner Input (DVB-S/DVB-T/DVB-C/QAM/ISDB-T/ATSC-T) ASI and IP sources. After multiplexing and de-encryption with CAM module, it gives content out through ASI, IP as well as various video/audio interfaces. Its video/audio outputs support professional HD/SD-SDI, YPbPr, HDMI, stereo balanced audio, stereo unbalanced audio and S/PDIF digital audio and CVBS, which can greatly satisfy the professional users needs. QuestTel's IRD support Dolby AC 3 audio pass through and closed caption for both 608 and 708 captioning. With the CAM/CI slot, B-IRD-HD-PRO-Q can support one channel Tuner, ASI or IP de-scrambling and give transparent signal output. User can operate the device by using front panel LCD or NMS/SNMP software or Webpage-based NMS. Also users can choose to have an optional ASI output which can pass through the encryption data source directly from tuner.

Input Interface
Tuner 1 Tuner(DVB-S/S2)
DVB-S2: 950 MHz~2150 MHz, symbol rate:
QPSK 1~45Mbauds, 8PSK 2~30Mbauds
ASI 1 ASI IN (support 188/204 package format)
IP 1 IP (100M, RJ45 Port) UDP/RTP
Input Interface Optional Tuner DVB-C: 47 MHz~860 MHz, 16/32/64/128/256 QAM
DVB-S: 950 MHz~2150 MHz, symbol rate: 2~45Mbauds
DMB-T: 146MHz ~862 MHz, 6/7/8 M bandwidth
DVB-T: 146MHz ~862 MHz, 6/7/8 M bandwidth
ISDB-T: 153 MHz ~862 MHz, 6/7/8M bandwidth
ATSC-T: 54MHz~858MHz, 6M bandwidth
DVB-T2: 44MHz ~1002 MHz, 6/7/8 M bandwidth
Video Decoding MPEG-2, MPEG-4/H.264
Audio Decoding MPEG1 Layer 2, MPEG2 Layer 2 DD AC/3, HD-AAC(v2), LC-AAC

Output Port
ASI Output 2 ASI output(after multiplexer)
2 ASI output(tuner input pass through)
IP output  UDP&RTP @ 1MPTS
Video Output 1xCVBS: 576i@25, 480i@29.97
1xYPbPr: 1080i@25/29.97/30, 720p@50/59.94
1xHD/SD-SDI: 1080i@25/29.97/30, 720p@50/59.94,
576i@25, 480i@29.97
1xHDMI: 1080i@25/29.97/30, 720p@50/59.94
Audio Output Stereo unbalanced audio: BNC interface
Stereo balanced audio: XLR interface (Digital AES/EBU)
Digital audio: SPDIF (Toslink /Digital-Optical)
Input Level -65~-25dBm
NMS Port Ethernet Port 10/100M Management: front panel (LCD + Keyboard);
Network (NMS/SNMP);
Web-based NMS Management
Front Panel LCD Monitor
Protocols TS Over IP : UDP, NMS : UDP

Dimensions ( L×W×H) 482mm*360mm*44mm
Approx weight 3.2kg
Power <20W(Max)
Temperature 0~45℃(Operating), -20~80℃(Storage)
