1 Ch HD-SDI + 2 Ch IP Over Fiber Extender Kit
L-1SDI/2IP-FE-TX/RX
The L-1SDI/2IP-FE-TX/RX is a high performance, and reliable, 1-channel SD/HD-SDI video optical transceiver, which perform real-time, loss-free and high-quality video transmission over an optical singlemode fiber line. Besides, L-1SDI/2IP-FE-TX/RX provides two Ethernet interfaces sharing 100M bandwidth, one bi-directional RS485 data channel, and optional audio/contact closure/RS422/RS232 data transmission, which can be widely used in TV live broadcast, high-definition video conference, high-definition video monitoring, intelligent transportation system and public security system.
| Video Interface | |
| Connector | BNC |
| Fiber Connector | ST/PC |
| Bit rate | 1.485Gb/s and 270Mb/s auto adaptive |
| Impedance | 75Ω |
| Return loss | >15dB |
| Output level | 800mVp-p±10% |
| Rise and fall time（HD-SDI） | ≤270ps |
| Rise and fall time（SD-SDI） | ≤1.50ns |
| SD-SDI Alignment jitter (1KHz) | ≤0.2UI |
| SD-SDI Timing jitter (10Hz | <0.2UI |
| HD-SDI Alignment jitter (100KHz) | ≤0.2UI |
| HD-SDI Timing jitter (10Hz) | <1.0UI |
| Standard |
Comply to SMPTE-292M HD-SDI and SMPTE-259M SD-SDI standard |
| Audio Interface (Optional) | |
| Connector | PHOENIX connector |
| Impedance | Input high-impedance, output 600Ω |
| Quantization grade | 20bits |
| Sample frequency | 48KHz |
| Audio input/output voltage | 2VP-P |
| Bandwidth | 20Hz~20KHz |
| Total Harmonic Distortion | 0.1% |
| Impedance | 600Ω |
| FE Interface | |
| Connector | RJ45 |
| Frame length | From 64 bytes to 1552/1536 bytes |
| Working mode | Auto-negation by default |
| Bit rate | 10/100Mb/s |
| Duplex | Half/full duplex |
| Port VLAN |
Default settings: closed. All the port share the same LAN. |
| Flow Control | Default settings: open |
| Standard |
IEEE802.3u 100Base-TX / IEEE 802.3 10Base-T |
| RS485 Interface | |
| Connector | PHOENIX connector |
| Baud rate | 0~115.2Kb/s |
| Bit error ratio | <10-9 |
| Duplex | Half-duplex |
| CONSOLE Interface | |
| Connector | RJ45 |
| Baud rate | 19200 |
| bits | 8 |
| Stop bit | 1 |
| parity check | None |
| EMU/EMU-EX Interface | |
| Connector | RJ45 |
| Bit rate | 10Mb/s or 100Mb/s auto adaptive |
| Power and Consumption for desktop equipment | |
| Power supply | DC 12V |
| DC input voltage range | 8V~14V |
| Power consumption | 3W±10％ |
| Power and Consumption for rack mounting chassis | |
| Power supply | AC 220V /DC-48V |
| DC input voltage range | -36～-72V DC |
| AC input voltage range | 176~264V |
| Power consumption for each card | 3W±10％ |
| Environment Requirements | |
| Working temperature | -30～60℃ |
| Relative Humidity | ≤95％, no condensation |
| Storage temperature | -40～85℃ |
| Equipment dimension | |
| Dimension of Rack mounting chassis （with rack ear） | 330mm x 178mm x 482mm |
| Desktop equipment dimension | 180mm x 123mm x 30mm |
